Tracing from J.W. Parry's sketch 1852-1884

SPCAA/D/1/4/13

c.1884-1897

Francis Cranmer (1817 - 1903) Penrose, Unknown

1 darwing

Sketches depicting the construction of the dome scaffolding, executed on tracing paper in black and red ink.

Plan and section depicting detail of the scaffolding used for the restoration of the Thornhill paintings on the dome.

Access is strictly by appointment only with the architectural archivist. Material dating from 1990 to the present day is not currently available for public consultation. Some records are subject to a closure period of 75 years under the Data Protection Act.

item
