St Paul's Cathedral. Sketch for screen at W. end of choir.

SPCAA/D/1/11/16

1870

Elevation and plan of proposed open screen for the west end of the quire, executed on paper in black ink, grey watercolour, and pencil. The drawing has been mounted on cream card (while at London Guildhall).

Elevation and plan showing the proposed open screen for the west end of the quire.
